4 hauv 1 Theem Teeb

DREAM L800 BSWF
DREAM L800H BSWF

Cov ntsiab lus
DREAM L800 BSWF tab tom txav lub taub hau theem teeb, LED profile lub teeb tau txais txiaj ntsig thiab kev ua haujlwm siab 800W LED lub teeb dawb lub cav, cov pob uas nws kim heev suav nrog: cov khoom tso tawm; cov xim zoo heev; ntse gobos; suab nrov; zoom 1:10 zoom ntau yam; hluav taws xob dimming thiab strobe; CMY / CTO; iris rau beam kho thiab rotating gobo log thiab animation log. Nws tseem nta infinite rotate framing system uas hlub los ntawm tag nrho peb cov neeg siv. Qhov kawg thiab ua tiav framing system tuaj yeem muab cov neeg tsim teeb pom kev tsis muaj kev txwv tsis pub muaj zog thiab cov ntaub ntawv zoo nkauj nrog cov duab uas nws tsim ntawm lub kaum sab xis sib txawv los ntawm tag nrho txoj kev nkag.

● Lub teeb qhov chaw: 800W Dawb LED lub teeb lub cav
● Zoom ntau yam: 5℃~ 58 degree
● CMY + CTO
● Ib lub log xim
● Ib lub log gobo tig
● Ib lub log tas gobo
● Ib lub log animation
● Ib qho ua tiav & infinite rotate framing system
● Motorized iris, kev hloov kho linear
● Ib lub prism, ib lub lim dej khov
● Dimmer: linear hloov

Xa kev nug

Product Details of 4 hauv 1 Theem Teeb

Hluav taws xob Specification

Kev tawm tswv yim Voltage: AC200-240V 50/60Hz

Input Power: 1080W, PF Ntau dua lossis sib npaug rau 0.98

Qhov siab tshaj tawm tam sim no: 5.4 A

Lub teeb Source

Lub teeb ci: 800W Dawb LED lub teeb lub cav (xaiv hom ci ci lossis siab CRI hom)

CRI: Ra Ntau dua lossis sib npaug rau 70 (DREAM L800 BSWF siab brightness);

Ra Ntau dua lossis sib npaug rau 90 (DREAM L800H BSWF siab CRI)

LED xav tau lifespan: 20000 Teev

Optics& Cov ntaub ntawv Photometric

Frontal lens: Siab- txhais lo ntsiab muag nrog anti-paj yeeb yaj kiab, txoj kab uas hla ntawm lub lens frontal: 180 mm

Zoom ntau yam: 5℃~ 58 degree

Xim System

CMY infinite mixing, tso zis siab saturated xim (RGB), xim ntshiab.

CTO xim kub linear adjustable 3200-6200K

Ib lub log xim, muaj 7 xim lim ntxiv rau qhib (nrog rau CRI boost lim), tuaj yeem ua tau ob txoj kev scrolling, tuaj yeem tsim cov teebmeem ntawm zaj sawv, stepping, zawv zawg ploj thiab random xim hom.

Gobo System

Ib lub log gobo tig nrog 6 gobos, lub gobos tuaj yeem ua indexing thiab bi-directional rotating, tuaj yeem ua tus kheej- kev sib hloov, tsim cov teebmeem ntawm cov dej ntws thiab co, lub log gobo tuaj yeem tswj tau ntawm 16 ntsis.

Ib qho zoo li qub gobo log nrog 9 gobos + 1 qhib, lub log gobo tuaj yeem tsim cov nyhuv bidirectional ntws.

Ib lub log animation, tuaj yeem ua raws li huab, hluav taws kub thiab dej ntws rau cov teebmeem.

Framing System

Ib qho ua tiav infinite rotatable framing system, 4 x tus kheej tswj tau tag nrho cov ntaub thaiv npog nrog lub kaum ntse ntse sib txawv los ntawm tag nrho txoj kev nkag, tuaj yeem ua rau cov duab kos duab 360℃infinite rotating thiab raug qhov chaw, tsis muaj kev cuam tshuam.

Cov khoom siv cuam tshuam

Ib qho prism nrog kev sib hloov hauv ob qho tib si

Ib Frost lim

0-100% hluav taws xob dimming tswj, ntau yam kev xaiv ntawm dimming nkhaus

Electronic strobe, nrog kev hloov ceev ntawm 1 txog 25 flashes ib ob, ntau txoj kev xaiv strobe

Kev kub ceev motorized iris 5-100% linear hloov, built-in macro function

Fixture Movement

PAN=540℃- 16 ntsis

TILT=270℃- 16 ntsis

Electronic Control

DMX Channels: 32 Ch / 35 Ch / 60 Ch

Tswj Cov Txheej Txheem: DMX512, RDM; (optional: Art-Net, sACN, wireless function)

Cov ntaub ntawv Portals:XLR-3 + XLR-5 Hauv/Thru ; (optional Ethernet chaw nres nkoj: RJ45 Hauv / Tawm)

Fais fab Portals: Xauv lub zog hauv

Daim ntawv qhia zaub mov: 3.5 "LCD npo; xaiv Suav thiab Askiv, cov ntawv qhia zaub mov muaj kom pom 180℃thim rov qab

Ua-hauv tus kheej- roj teeb rov qab, cov ntawv qhia zaub mov tuaj yeem hloov kho yam tsis muaj hluav taws xob (yeem); txhawb kev txuas lub txhab nyiaj fais fab kom nkag mus rau cov ntawv qhia zaub mov thiab kho qhov chaw nyob code thiab lwm qhov chaw

Hluav taws xob sensors kuaj, kiv cua ntse nrhiav thiab tswj

Eco hom (pw tsaug zog hom thaum standby)

Tsis yog - kov cov magnetic encoder positionable system rau lauj kaub - qaij

Loj & Nyhav

Fixture loj: (462X462X812) mm (Integrated nuv)

Qhov hnyav: 44 kg

Txoj kev loj: (710X550X865) mm (1 txoj hauj lwm)

Txoj kev hnyav: 30 kg

Thawv loj: 545x525x930 mm (1 txoj haujlwm)

Cov xwm txheej ua haujlwm

Yam tsawg kawg nkaus thiab siab tshaj plaws ambient kub: -20℃~ 40 degree

Kev tiv thaiv kev ntsuas: IP20
