Ntxuav cov chaw nqaj

Hluav taws xob

Inpution voltage: ac 100-240 v 50 / 60Hz

Cov hwj huam tawm: 45 0 w, pf ntau dua lossis sib npaug rau 0.98

Qhov siab tshaj plaws tam sim no: 4.5 a



Teeb Tau Qhov Teeb

Qhov Chaw Teeb: 300W Dawb LED Module

LED module purple: 20000 teev



Optics & Photometric cov ntaub ntawv

Lens: High-txhais lub lens nrog anti-reflective zaj duab xis

Zoom ntau: Beam / chaw 4 degree ~ 35 degree; Ntxuav: 8 degree ~ 45 degree



Xim System

CMY Infinite sib xyaw, tawm kom muaj cov xim noo (RGB), xim ntshiab.

CTO xim kub liner hloov kho kev hloov kho 3200-6500 k

Ib lub log xim, muaj 9 daim ntawv lim dej ntxiv rau qhib (suav nrog cov lim lim), tuaj yeem tsim cov txiaj ntsig ntawm zaj sawv, kauj ruam, zawv zawg fade thiab random xim hom.



Gog Teb

Ib qho tig gobo log, muaj 8 gogbos featuring qhov chaw thiab Bidirectional tig, tuaj yeem yog kev sib hloov ntawm kev sib hloov, tsim cov teebmeem ntawm cov dej ntws, co; 16b tswj.

Ib qho zoo li qub gobo log, muaj 11 gogos ntxiv qhib, lub log gebo tuaj yeem tsim cov nyhuv ntawm bi-directional scrolling.



Cov Khoom Siv Ua Haujlwm

Ob lub prisms ({3- facet + 6- Facet lub voj voog), tuaj yeem tig hauv ob qho kev qhia, ua raws li kev tsom xam.

Ib lub lim te, tuaj yeem ua raws qhov tsom

0-100}}% hluav taws xob dimmer tswj, 4 kev xaiv ntawm kev dimming curves, 4 kev xaiv ntawm Dimming Speeds

Hauv lub cev xwm txheej nrawm ntawm 1 txog 25 flashes ib ob, ntau txoj hlab xaiv



Fixture Zog

Pan=540 degree - 16 ntsis ntsis

Qaij=270 degree - 16 me ntsis



Kev tswj tshuab hluav taws xob thev naus laus zis

Channel: 23CH / 26CH / 37CH

Tswj cov kev cai: DMX512, RDM; Kos duab-net, SACN, wireless muaj nuj nqi (yeem)

Tswj Portals: XLr -3 + xlr -5; RJ45 (Yeem)

Ntawv qhia zaub mov: 2.4 "LCD screen; kev xaiv cov lus Suav thiab lus Askiv, cov ntawv qhia muaj los tso tawm 180 Degree Reversely

Built-in rechargeable roj teeb, Menu txheem hloov muaj tsis muaj lub zog (yeem)

Txhawb nqa cov txhab nyiaj sab nraud kom nkag mus rau cov ntawv qhia zaub mov kom teeb tsa txoj cai thiab lwm cov chaw

Kev xav tau hluav taws xob nrhiav kom tau, kiv cua ntse nrhiav kom tau thiab tswj

Eco hom (pw tsaug zog hom thaum sawv ntsug)

Tsis-kov cov hlau nplaum encoder posreable system rau pan-tilt.



Loj & Nyhav

Fixture Loj: (389x271x719) hli

Fixture ceeb: 24.5 kg

Dav Dav Dav Xwm Loj: (1050 x 570x 775) hli 775) mm (2 txoj haujlwm)

Dav Dav Dav Hlau Qhov hnyav: 40 kg



Kev Ua Haujlwm

Yam tsawg kawg thiab qhov siab tshaj plaws kub: {{{0} degree ~ 40 degree

Kev Tiv Thaiv Kev Tiv Thaiv: IP 20 20

PS cov lus qhia thiab cov ntaub ntawv raug hloov pauv yam tsis muaj kev ceeb toom. Ntsuas cov ntaub ntawv sim yuav sib txawv raws li ntau yam suav nrog tab sis tsis txwv rau: ib puag ncig kev mob, hluav taws xob, thiab lwm yam.
